APPENDIX 1: COMPONENT TIGHTENING TORQUE
Component Tightening torque
Seat clamp 6 N.m +/- 1N.m
Head tube No play/No hard spots
Fork/Stem 6 N.m +/- 1N.m
Crankset arm cap 1.5 N.m +/- 0.5N.m
Handlebar/Stem 6 N.m +/- 1N.m
Saddle 17 N.m +/- 1N.m
Disc brake screw 5 N.m +/- 1N.m
Brake adapter 7 N.m +/- 1N.m
Brake caliper 7 N.m +/- 1N.m
Brake lever 7 N.m +/- 1N.m
Bottom bracket 45 N.m +/- 5N.m
Derailleur cable hanger screw 2 N.m +/- 0.5N.m
Rear derailleur 9 N.m +/- 1N.m
Cassette 40 N.m +/- 5N.m
Gear shifter 7 N.m +/- 1N.m
Rear derailleur cable 6.5 N.m +/- 0.5N
Front wheel axle 10 N.m +/- 1N.m
Rear wheel axle 26 N.m +/- 2N.m
Magnet ( cassette lock ) 40 N.m +/- 1N.m
Speed sensor 1 N.m +/- 0.5N.m
Bottle holder screw 2.5 N.m +/- 0.5N.m
Motor nut 35 N.m +/- 1N.m
Motor disc nut 4 N.m +/- 1N.m
