SECTION 1
INTRODUCTION
1.5 Controls and Features
INSTRUMENT RIGHT SIDE
Sample Chamber Lever
Opens and closes the sample chamber. Closing the sample cham-
ber locks the sample holder within the chamber. The chamber
should remain closed, except when loading or removing samples.
Closing the chamber initiates the measurement cycle or the
“Standby” mode (indicated by READY on the display screen) if no
sample is present.
INSTRUMENT INTERIOR
The thermocouple (TC) head and thermocouple head connector are
accessed by removing the chamber access cover from the top of the
instrument.
INSTRUMENT REAR PANEL
Signal Chime
Sounds a short chime at the conclusion of each measurement cycle
and a long chime when certain fault conditions exist. Turn the shut-
ter wheel to adjust volume.
Serial Data Port
For asynchronous serial communication with a printer or computer.
The serial port uses a DB9 connector at RS-232 voltage levels.
See Appendix F for more information.
15
