SECTION 2
GETTING STARTED
2.8 Changing Fuses
28
To access the main fuses:
1
Turn power off and disconnect the power cord.
2
Use a small screwdriver to open the fuse door.
Fuse Specifications:
115 V Setting: 1/8 ampere time-delay type, 1/4” x 1-1/4”
(2 required). 230 or 240 V setting: 1/16 ampere time-
delay type, 1/4” x 1-1/4” (2 required).
Refer to Specifications (Appendix A).
3
Pull fuse holder out. (Note the orientation of the
voltage rating, the fuse holder must be replaced
with the correct voltage showing in the window.)
4
Remove faulty fuse and replace with new fuse
of the correct rating.
5
Replace fuse holder with the correct voltage
orientation.
For continued protection against fire hazard, only use
fuses of the correct type and rating.
