VARI❋LITE - VL2200 SERIES SPOT LUMINAIRE USER’S MANUAL
90 22-May-01 02.9673.0001 A
B2M1
Gobo
NoSn
Aux Board 2, Motor 1,
Rotating Gobo Wheel,
Sensor Not Found
Rotating gobo wheel power not
connected, motor not moving
- Connect rotating gobo wheel
power at motor
Rotating gobo wheel sensor not
connected
- Connect rotating gobo wheel
sensor
Rotating gobo wheel movement
restricted or impeded
- Remove obstruction
Rotating gobo wheel sensor is
faulty
- Replace rotating gobo wheel
sensor assembly
Aux Board 2 is faulty
Replace aux board
B2M1
Gobo
SAct
Aux Board 2, Motor 1,
Rotating Gobo Wheel,
Sensor Always Active
Rotating gobo wheel power not
connected and rotating gobo wheel
aligned with sensor
- Connect rotating gobo wheel
power at motor
B2M2
Indx
NoSn
Aux Board 2, Motor 2,
Rotating Gobo Index,
Sensor Not Found
Rotating gobo index power not con-
nected, motor not moving
- Connect rotating gobo index
power at motor
Rotating gobo index sensor not
connected
- Connect rotating gobo index
sensor
Rotating gobo index movement
restricted or impeded
- Remove obstruction
Rotating gobo index sensor is faulty
- Replace rotating gobo wheel
sensor assembly
Rotating gobo wheel has error pre-
venting index to calibrate properly
- Ensure rotating gobo wheel is
functioning properly
Aux Board 2 is faulty
Replace aux board
Table 1: VL2200 Troubleshooting Guide (Continued)
Error Display Description Possible Cause and Remedy
