VARI❋LITE - VL2200 SERIES SPOT LUMINAIRE USER’S MANUAL
6 22-May-01 02.9673.0001 A
Components
VL2200 Series Spot Luminaire
The following illustration shows the major luminaire components and controls.
Head Assembly
Upper Enclosure
Truss Hook
Assembly
AC Input Cable
Yoke
Bracket Assembly
Assembly
Removable Lamp Assembly
(to access lamp for replacement)
Beam Adjustment Controls
Vertical
Horizontal
Focus
Captive Knob
for lamp access
(does not adjust
beam)
Main Power
Switch
AC Input Cable
Data In
Data Thru
Power and Data
LED Indicators
Input Panel Components
Menu Display
Product Label ID
