MENU SYSTEM : CUES AND SEQUENCES
4
02.9673.0001 A 22-May-01 69
Cue Operations
The following section provides instructions for performing cue, sequence, and
playback operations.
Note: The Mod, Del, PCue, PSEQ commands will all display "---" if no cues
have been stored.
Note: After 10 seconds of inactivity at the display, it will change to the default state
showing the address.
To use the menus:
The data stored by the luminaire is “last takes precedence.” This means the last
command received by the luminaire will be the basis of the cue to be stored.
To clear all input data and timing values from previous tests or cues, cycle power to
the luminaire with DMX data cables disconnected. This will reset parameter’s data
and timing values to defaults.
Set position:
1. Press [Menu].
2. Press [Up]/ [Down] arrows until Man appears. Press [Enter].
3. Press [Up]/ [Down] arrows until desired parameter appears. Press [Enter].
4. Press [Up] / [Down] arrows to adjust value. (The values wrap from 0 to 255
in either direction. Pan and Tilt values operate in a range of 0-4095, and wrap
also.) Press [Enter] to set value.
5. Parameter timing can be set using the Time sub-functions. This allows
timing to be added to Intensity, Pan & Tilt, Color, and Beam parameters.
