VARI❋LITE - VL2200 SERIES SPOT LUMINAIRE USER’S MANUAL
104 22-May-01 02.9673.0001 A
Pan/Tilt Accuracy
0.3° resolution.
Weight
49.5 lbs (22.5 kg) - VL2201™
50 lbs (22.7 kg) - VL2202™
Spacing
Refer to illustration on page 19.
Optical
Source
400 Watt Short-Arc Lamp, 5500°K, 75CRI (VL2201™)
700 Watt Short-Arc Lamp, 5600°K, 80CRI (VL2202™)
Reflector
Precision glass reflector with dichroic cold mirror coating.
Peak field design - VL2201™
Flat field design - VL2202™
Operational
Power Requirements
All VL2200 models are powered through standard AC power distribution and require
three amps to twelve amps depending on the AC supply voltage and product model.
All VL2200 models operate from 100-240 +/- 10% VAC, 50/60 Hz
Operational Temperature
-20° to 113°F (-29° to 45°C) *
* The VL2202 model will operate up to 120°F (50°C) at voltages above 100 VAC.
Cooling
Forced air cooling.
Control
Compatible with the VARI❋LITE Virtuoso™ control system and a wide variety of DMX
consoles.
Mounting Position
The luminaire can be mounted and operated in any orientation.
