02.9673.0001 A 22-May-01 103
Technical Specifications
Technical SpecificationsTechnical Specifications
Technical Specifications
Mechanical
Intensity Control
Full-field dimming designed for both smooth timed fades and strobe effects.
Color/Fixed Gobo Wheels
Two, 12-position wheels, each providing 11 easily loaded positions (and 1 open) for
user-selectable color and gobo choices.
Rotating Gobo Wheel
Six-position rotating gobo wheel with five rotatable, indexable gobo positions and one
open position.
Zoom Optics
Zoom angle of 2.8 to one. Continuously variable field angle from 13° to 35°
(VL2201™) or 19° to 43° (VL2202™). Programmable over a timed range of 2
seconds to 20 minutes.
Edge and Pattern Focus
Variable beam focus to soften edges of gobos or spots.
Beam Size
A mechanical iris provides continuous beam size control for both rapid changes and
smooth timed beam angle changes in addition to the zoom optics.
Pan/Tilt
Smooth, time-controlled continuous motion by way of a three-phase stepper motor
system. Range: Pan - 540° , Tilt - 270°.
A
PPENDIX
B.
A
PPENDIX
B.
