Vari Lite VL2202 - Beam Control; Beam Iris; Edge; Strobe

OPERATION : DMX MAPPING
3
02.9673.0001 A 22-May-01 35
Beam Control
Beam Iris
Edge
Strobe
Zoom
Table 3-4: DMX Map for Beam Iris
% Value DMX Value Action
0 0 Closed
100 255 Open
Table 3-5: DMX Map for Edge
% Value DMX Value Action
0 0 Blooms In
100 255 Blooms Out
Table 3-6: DMX Map for Strobe
% Value DMX Value Action
00-2Open
1 3-5 Closed
2 6-7 Slow Random
3 8-10 Med Random
4 11-12 Fast Random
5-100 13-255 Speed Range
Table 3-7: DMX Map for Zoom
% Value DMX Value Action
0 0 Narrow
100 255 Wide
