Vari Lite VL2202 - Features; Overview; Features Overview; Specific Features

DESCRIPTION : FEATURES
1
02.9673.0001 A 22-May-01 5
Features
Overview
The VL2200 series spot luminaire is available in two
different configurations - VL2201™ luminaire and
VL2202™ luminaire. The model number can be found
next to the power switch.
Standard Features
All VL2200 series spot luminaires have the following
standard features:
• Variable beam focus to soften the edges of gobos or
spots and enable gobo morphing.
• Full field dimmer to allow smooth timed fades and fast blackouts.
• A mechanical iris which provides continuous beam size control for both rapid
beam size changes and smooth timed beam angle changes.
• Rotatable gobo wheel which contains five individually rotatable, indexable gobos.
• Two, 12-position wheels, each providing 11 easily loaded positions (and 1 open)
for interchangeable dichroic color and gobo selections.
• Power factor corrected arc power supply for a Philips arc lamp.
• Control by DMX512 protocol.
• Two truss hook brackets for versatile hanging configurations.
Specific Features
Each individual configuration has the following features:
VL2201 Luminaire
• 400 watt arc source.
• Zoom optics system with a zoom angle of 2.8 to one.
• Smooth reflector which produces a peaked or flat field.
VL2202 Luminaire
• 700 watt arc source.
• Zoom optics system with a zoom angle of 2.8 to one.
• Faceted reflector designed for an optimal flat field.
