1. System Overview
EzRay Air (Model: VEX-P300) User Manual 5
ENGLISH
Available Option Items
No. Figure Option name
1
Cradle
2
Rectangular Cover 2x3 (3x2)
FOV: 2x3 cm, 3x2
(This cover can be used as both
2x3 and 3x2.)
3
Rectangular Cover 4x3 (3x4)
FOV: 4x3 cm, 3x4 cm
(This cover can be used as both
4x3 and 3x4.)
4
Remote Exposure Switch
5
Base Holder*
6
Hand/Neck Strap
* In case a tripod is used with the Base Holder, refer to the specifications below.
Fixing bolt size: 3/8 inch
Maximum supportable weight: about 5 kg
Minimum height: > 130 cm
More than 3 columns are required.
When using a tripod with 3 columns, make sure to have space of at least 1 m in width on
the bottom.
