1,890 mm (L) x 2,233 mm (W) x 2,420 mm (H)
2,805 mm (L) x 2,233 mm (W) x 2,420 mm (H)
If the ceiling height is less than 2392 mm (without Base) /
2420 mm (with Base) (= max. height of the column + 100
mm), refer to Appendix C. Limiting the Column Height to
lower the max. the height of the column.
Lead Thickness
≥ 1 mm
The width of the Entrance
The door of the X-ray room should have a clearance of more than 800 mm (31.5”)
wide.
Floor Area
The floor of the X-ray room must be stable and level for system balance.
The floor must be able to support a minimum weight of 500 kg/m2 (110 lbs./feet2)
Protection against Radiation
⚫ To protect against radiation hazards, follow all federal and municipal
requirements.
⚫ During exposure, the operator should follow applicable radiation shielding
requirements and remain at least 2m (7’) from the source of the radiation.
⚫ Maintain visible contact with the patient and a clear view of indicators such as the
warning lamp and imaging status on the PC.
