Vatech PaX-i Insight

6. Completing Miscellaneous Works
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 75
English
6. Completing Miscellaneous Works
6.1 Assembling Base Cover (Optional)
When removing the semi-transparent tape, be careful not
to scratch the surface of the equipment.
1. Assemble the base cover.
Base Cover
2. Fix the base cover with 3 truss bolts.
Truss Bolt
M5 x 8
(Part No. 26)
Cross Head
Screw Driver w/
Magnetic Tip
6 mm / 0.24”
