3. Before Installing the System
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 25
English
4. Put the PC System (Optional) down on the floor.
5. Separate two side EPS (A, B). The resulting view is as follows.
Do not discard these EPS (A, B), so that they are reused
later when the CEPH unit is installed.
6. Separate two side EPS (A, B). The resulting view is as follows.
7. Remove the case column front cover
