Vatech PaX-i Insight

3. Before Installing the System
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 27
English
3.3.2 Box No. 2 - Base Unit
Component
Size (mm / inch)
Weight (kg / lbs.)
Base
1046 (L) x 1056 (W) x 185 (H) /
41" (L) x 41.5" (W) x 7" (H)
47 / 103
Removing the cover
1. Open the box cover, the Base Cover appears.
