4. Installing the Equipment: Base Stand (Optional)
44 PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
Combining Column and Wall Brackets
1. Prepare the wall bracket.
Wall Bracket
(Part No. 35)
2. Combine the column and wall brackets in the following manner with the 2 Wrench
Bolts.
Allen Wrench
6 mm / 0.24”
Wrench Bolt
M8 x 25 w/
Spring and Flat
Washers
(Part No. 34)
Monkey Wrench
n/a
Nut
M8
(Part. No. 34)
Do not tighten the bolts fully yet.
