4. Installing the Equipment: Base Stand (Optional)
54 PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual
Wooden Floor
Wood Screws
M12 x 70
(Part No. 34)
Hammer Drill
L = 200 mm
(7.9”)
1. Secure the base unit using the wood screws.
