4. Installing the Equipment: Base Stand (Optional)
PaX-i Plus / Insight (Model: PCH-30CS) Installation Manual 61
English
When the Ceph unit is tilted to the right or left
1. To adjust the Align bolt, untighten four Wrench Bolts (M8) slightly.
2. Adjust the level of the Ceph unit on both the right and left sides until the bubble on
the Spirit Level sensors in the middle, by adjusting Align Bolt (M10).
