2. Choosing an Installation Site
18 PaX-i Plus / Insight Installation Manual
2.5 Exposure Switch Installation Options
There are three options for installation, depending on the configuration of the site.
Nevertheless, the 2
nd
option is preferred.
Option No. 1:
The user operates the Exposure Switch from inside the X-ray room.
Option No. 2:
The user operates the Exposure Switch from outside the X-ray room. The Exposure
Switch holder is mounted on the wall.
To Next Page
