4. Installing the Equipment: Base Stand (Optional)
PaX-i Plus / Insight Installation Manual 63
4.10 Tightening the Bolts
1. Tighten the joint bracket bolts.
Allen Wrench 6 mm / 0.24”
Monkey
Wrench
n/a
