3. Before Installing the System
30 PaX-i Plus / Insight Installation Manual
3.3.2 Box No. 2 - Base Unit
Component Size (mm / inch) Weight (kg / lbs)
Base
1046 (L) x 1056 (W) x 185 (H) /
41" (L) x 41.5" (W) x 7" (H)
47 / 103
Removing the cover
1. Open the box cover, the Base Cover is appeared.
