Vdwall LVP615S - Front Panel and Remote Control Operation; Control Interface Overview

LVP615S
使用说明
14
4.1 Front panel buttons and remote control schematic
1
2
6
10
3
9
4
5 8 7
11
Chapter 4 Front panel and remote control instructions
LVP615S supports front panel button, remote control, RS232 and LAN
control. Same printing on remote control buttons and front panel
buttons,same button functions. The instructions are as below.
