LVP615S
使用说明
8
3.3 Hardware connection diagram
loop output
3.2.4 Other ports
Port
Description
LAN
TCP/IP local area network control
interface
USB
USB communication port
RS232 IN
Serial communication interface, used to
connect the RS232 port of PC to realize
PC software control.
RS232 LOOP
Serial communication cascading output
for connecting the RS232 IN of next unit,
through single PC can control several
units.
RF
Antenna interface of wireless control
function
