Vdwall LVP615S - Input Video Signal Setup

LVP615S
使用说明
33
Setup
OK
knob
OK
OK
6.2 Input video signal setting
Press button to enter setup menu. Press↓ button to select
and press to enter this item.
2.Input video signal
2.1
DVI EDID
1280x1024_60
2.2
V1/V2 backup
off
2.3
VGA1/VGA2 backup
off
2.4
HDMI/DVI backup
off
2.5
V2 or YPbPr
V2
2.6
Switch mode
one key switch
6.2.1 DVI EDID
LVP615S supports custom DVI EDID. In concert with “custom
output format” ， LVP615S can realize DVI input image and output
image pixel to pixel display. LVP615S supports 16 fixed DVI EDID and
custom EDID. Normally the parameters setting should be consistent
with“custom output format”
（
refer to page28 ).
Operation steps：In the menu 2.1 DVI EDID， rotate to
select suitable resolution and press to save data. After save data,
need press to enter“2.1 custom DVI EDID” menu to set
2.1.1custom width、2.1.2custom height and
and press ↓ to enter APPLY and press “OK” to make parameters
effective.
2.
Input video signal
2.1.3 custom V frequency
