2.1custom DVI EDID
2.1.1
Cus.
width
1920
2.1.2
Cus.
height
1002
2.1.3
Cus.
V Freq.
60
2.1.4
Apply
OK to apply
6.2.2 Hot spare setting
LVP615S supports hot spare of input signals. When the current
input signal is lost. LVP615S will switch to the spare signal
automatically to avoid image interruption caused by the fault of signal
source.
2.Input video signal
2.1
DVI EDID
1280x1024_60
2.2
V1/V2 backup
off
2.3
VGA1/VGA2 backup
off
2.4
HDMI/DVI backup
off
2.5
V2 or YPbPr
V2
2.6
switch mode
one key switch
As shown in the above table，if ”2.2 V1/V2 backup on”, if V1
signal is lost, processor will switch to V2 automatically.
6.2.3 V2 or YPbPr selection
V2 and YPbPr of LVP615S share the same port and button. Need
configure. Default input is V2. If need YPbPr input, then need set this
