Vdwall LVP615S - Mosaic Functionality

LVP615S
使用说明
24
Mosaic
5.3 Mosaic operation
Mosaic Input： DVI
In Status： 1080p_60Hz
Input Image Size： 960x540
Input Image Start： （0，0）
Mosaic out size： 1920x1080
Mosaic out start： （0，0）
Mosaic PIP: off
Device ID:
1
Switch PIP/PBP mode
：
When PIP/PBP is on
，
press buttons M1
、
M2、M3 directly to select display mode fast.
Multiple units LVP615S cascading can drive huge resolution LED screen.
Only when the current input is DVI, press
on. LVP615S enters to Mosaic operation.
button and the indicator is
Press the button
again and the indicator is off, LVP615S exits Mosaic.
Note：
5.3.1 In mosaic mode, PIP display is available.
5.3.2 In following conditions ， LVP615S cannot enter mosaic
status.
（1）
The input signal selected is not DVI
；
（2）
Bypass is on
；
（3）
The resolution of DVI input signal is different from the
output resolution of processor.
