Manual Notes
© Vector Informatik GmbH Version 1.3 - 9 -
2.3 Vector Hardware Configuration
After successful installation you will find the configuration application Vector
Hardware in the Control Panel. The tool gives you information about the connected
and installed Vector devices. Furthermore the settings can be changed there.
Executing Vector
Hardware Config
Note: Under Windows XP and Windows Vista respectively the way in which Vector
Hardware Config is started depends on which view is configured:
Category view under XP:
Start | (Settings) | Control Panel
, click in the left part of the
window for further Control Panel options followed by
Vector Hardware.
Category view under Vista:
Start | (Settings) | Control Panel
, click in the right part of the
window for Additional Options followed by
Vector Hardware.
Classic view under XP and Vista:
Start | (Settings) | Control Panel, click Vector Hardware in the list.
The tool is split into two windows. The left windows lets you access the installed
Vector devices, the right window displays the details of the selection. The following
nodes are available in the left window:
Hardware
Hardware Each installed Vector device is shown in
. Additional details on the
available channels are shown in a tree view. Status information on the device
components and channels are also shown in this dialog.
In Application all available applications are shown with their configured channels. If
you click on an application, all of its channels are displayed in the right pane on the
screen.
Application
The General information section contains general information on Vector devices and
applications.
General information
Information on all currently valid licenses is displayed in License. You can look there
to see which tools and applications are currently licensed.
License
