C&C Mode

Initiating the C&C Mode

NOTE: You must first configure the display head for access to C&C Mode as instructed in the EMR

Installation

Guide (V-R P/N 577013-758).

1. Press MODE button until the indicator at the bottom of the display points to SETUP.

2. The first C&C Mode category, LANGUAGE, displays in the Descriptor Field. Press NEXT to enter Language

Setup, or continue to press the button to step through the remaining C&C Mode Setup categories. Press

NEXT to enter any category once it displays in the Descriptor Field.

C&C Mode Setup Categories

• Language setup - sets the volume, currency, setup, and printer label descriptions.

• Display Syntax setup - sets the punctuation and decimal places for data displayed in the Preset, Register, and

Tot alizer Fiel ds.

• Tempe r atu re setup - sets optional temperature probe’s units to Fahrenheit or Celsius.

• Fuel Source setup - sets the meter ID, meter input signal type, and product descriptions.

• Meter Calibration setup - sets the calibration of the meter by product using one of three methods.

• Configure I/O setup - enables various inputs/outputs such as Emergency Stop and Remote Start & Stop

output.

• OEM Message setup - lets you enter the start up OEM message.

• Delivery Options setup - lets you enable/disable price changing within the delivery state as allowed by local

regulatory authority, select temperature compensation method, enable delivery timeout, and enable tank ID.

• Report Formats setup - lets you print or compose formats for the Delivery Ticket and Shift Report.

• Restart setup - allows you to reboot while maintaining current setups, or to reboot and reset all setup selections

to factory default settings as well as removing all current transaction records.

• Security Code setup - allows you to enable security code protection to limit access to selected Setup Mode

categories.

Instructions for setting up the C&C Mode setups are shown in the figures that follow. In some cases multiple

figures are used to explain sub-procedures within a C&C Mode category. Once you have entered a C&C Mode

category (pressing NEXT), do not press the or buttons in that setup if you do not intend to change a value,

because when you press ENTER, the change, even if unintended, will be accepted. If you want to view setup

settings without making changes, press NEXT to move ‘into’ a category’s setup and ENTER to ‘back out’ of the

setup.

IMPORTANT! If in a C&C Setup you press ENTER too many times, you may ‘back’ out of the C&C Mode and end

up somewhere in the Setup Mode menu. To reenter C&C Mode, follow the button presses in the diagram below:

C&C LANGUAGE

Press this ke

until you retu

to the desired

C&C Setup
