Vapor Extraction Riser Kit W/O Coupling Adapter
This kit contains parts needed to install a probe in a Vapor Extractor Riser that does not have a coupling adapter
(parts listed in Table 3 and shown in Figure 5):
Figure 5. Mag Probe Vapor Extractor W/O Coupling Adapter Installation Kit
Table 3. Vapor Extraction Riser Kit (W/O Coupling Adapter) - Part No. 846500-002
Quantity Description Part Number
2 Wire Nut 576008-461
1 Cable Tie 576008-482
1 Splice Enclosure 514100-357
1 Splice Kit Instruction Manual 576013-861
1 Riser Cap 331106-001
1 Gasket 331140-001
1 Cord Grip Bushing 330787-001
1 Cord Grip Nut 330594-001
12 inches Flex Conduit 576008-294
probes\nonvapr.eps
12 Inches Flexible Conduit
Splice Enclosure
4" NPT Riser Cap and Gasket
Cord Grip Bushing
Cord Grip Nut
Cable Tie
Wire Nuts
