Veeder-Root TLS-450PLUS Manual

Wiring Module Bay Devices LVDIM Module Wiring
21
LVDIM Module Wiring
Figure 19. LVDIM Module POS/Pulser Connections
Set SW1 (on module's PC board)
to the EXTERNAL position.
Set SW1 (on module's PC board)
to the INTERNAL position.
Set SW1 (on module's PC board)
to the INTERNAL position.
Common
Pulser
+12
PetroVend System 2
PV270 Pump Relay Board
LVDIM
LOW VOLTAGE DIS PENS ER INTERFACE MODULE
+
-
+
-
+
-
+
-
12
11
10
9
+
-
+
-
+
-
+
-
5
6
7
8
+
-
+
-
+
-
+
-
1
2
3
4
+
-
SOURCE
INPUT RATING
30 VDC MAX
0 1 AMP MAX
934-1.eps
Micon 200
Electronic Dispenser Head
Yellow #18 AWG
(Pulser Common Line)
Blue #18 AWG
(Volume Pulser Output)
GasBoy 9800 or Tokhiem 2600 Series
Electronic Dispenser Head
Pulse 1 (Red)
NC
Pulse 2 (Grn)
DC Ground (Wht)
DC Junction Box
Reference Control Drawing number 331940-008
CLASS 2 CIRCUITS
