Veeder-Root TLS-450PLUS Manual

Console Installation Mounting the Console
4
Figure 1. TLS-450/TLS-450PLUS Consoles Dimensions and Designated Conduit Knockouts
16'' 1-1/8" Typ.
1"
11''13''
1/2'' TYP.
1'' TYP.
12''
FRONT VIEW
5.925''
3-1/8''
3-1/8''
1-7/16''
18.35''
BOTTOM VIEW
tlsng\dim.eps
Mounting flanges w/ 1/4'' x 3/8''
slotted hole - typ 4 places
3-1/8''
1/2'' TYP.
5.925''
0.65''
4-5/8''
3-1/8''
3-1/8''
3-1/8''
TOP VIEW
Conduit entries to Module bay
3/4, 1 I.P.S. knockouts
(typ. 4 places)
Conduit entry for console power
0.540", 1/2 I.P.S. knockouts
Conduit entries to Module bay
3/4, 1 I.P.S. knockouts
(typ. 4 places)
Conduit entry for
console power
3/4, 1 I.P.S. knockouts
4-5/8''
0.65''
8-7/8''
