Veeder-Root TLS-450PLUS Manual

Wiring Module Bay Devices MDIM Module Wiring
20
MDIM Module Wiring
Figure 18. MDIM Module Pulser Connections
MECHANICAL DISPENSER INTERFACE MODULE
MDIM
L1
N
NC
NC
P1
P2
P3
P4
P5
P6
P7
P8
P9
P10
P11
P12
120 VAC
INPUT RATING
120 VAC MAX
0 30 AMP MAX
White
934-2.eps
Black
115 Vac Line (BLK)
Neutral (WHT)
Barrier
P/N: 7859
769780-008
Pulse
Transmitter
120 Vdc
Barrier
P/N: 7859
769780-012
Pulse
Transmitter
120 Vdc
Reference Control Drawing number 331940-008
Barriers and transmitters
must be UL Listed.
