3 Product description
VEGAPOINT 11 • Transistor with IO-Link
63008-EN-200527
3 Product description
3.1 Conguration
The scope of delivery encompasses:
•
VEGAPOINT 11 point level switch
•
Information sheet "Documents and software" with:
– Instrument serial number
– QR code with link for direct scanning
Note:
Optional instrument features are also described in this operating
instructions manual. The respective scope of delivery results from the
orderspecication.
This operating instructions manual applies to the following instrument
versions:
•
Hardware version from 1.0.0
•
Software version from 1.2.0
The VEGAPOINT 11 consists of the components:
•
Housing with integrated electronics
•
Processtting
•
Plug
1
2
3
4
5
Fig. 1: VEGAPOINT 11
1 Plug connection
2 LED illuminated ring
3 Instrument housing
4 Processtting
5 Sensor
Youwillndthetypeplateonthesensorhousing.
Thetypelabelcontainsthemostimportantdataforidenticationand
use of the instrument.
Scope of delivery
Scope of this operating
instructions
Constituent parts
Type label
