3 Product description
VEGAPOINT 11 • Transistor with IO-Link
63008-EN-200527
1
2
4
5
6
7
8
9
3
2019
www.vega.com
D-77761 SCHILTACH,
Made in Germany
VEGAPOINT 11
12...35V 100mW
s/n 1234567
PNP 250mA
IP65/67/69, TYPE 6P
PEEK, EPDM, 316L
MWP 25bar (2500kPa)
Fig. 2: Layout of the type label (example)
1 Product name
2 Serial number
3 Voltage supply and signal output
4 Protection rating
5 Permissible process pressure
6 Material wetted parts
7 QR code for device documentation
8 Fabrication year
9 Approvals
Move to "www.vega.com"andenterinthesearcheldtheserial
number of your instrument.
Thereyoucanndthefollowinginformationabouttheinstrument:
•
Order data
•
Documentation
•
Software
Alternatively,youcanndallviayoursmartphone:
•
Scan the QR-code on the type label of the device or
•
Enter serial number manually in the VEGA Tools app (available
free of charge in the respective stores)
3.2 Principle of operation
The VEGAPOINT 11 is a capacitive point level sensor for point level
detection
It is designed for industrial use in all areas of process technology and
can be used in water-based liquids.
Typicalapplicationsareoverllanddryrunprotection.Withathe
small sensor unit, VEGAPOINT 11 can be also mounted e.g. in thin
pipelines. The sensor allows use in vessels, tanks and pipes. Thanks
to its simple and robust measuring system, VEGAPOINT 11 is virtual-
lyunaectedbythechemicalandphysicalpropertiesofthemedium.
