Vega VEGAPOINT 11 - Device Communication IO-Link

23
10 Supplement
VEGAPOINT 11 • Transistor with IO-Link
63008-EN-200527
Voltage loss < 3 V
Switching voltage < 34 V DC
Blocking current < 10 µA
Voltage supply
Operating voltage 12 … 35 V DC
Max.powerconsumption 1 W
Electrical protective measures
Potential separation Electronics potential free up to 500 V AC
Protection rating
Connection technology Protection according to
EN 60529/IEC 529
Protection according to UL 50
M12x1plug IP66/IP67/IP69 Type 6P
Altitude above sea level up to 5000 m (16404 ft)
Overvoltage category I
Protection rating (IEC 61010-1) III
Pollution degree 4
Output variable - Transistor output/IO-Link
Output signal Transistor output PNP/NPN
Output signal IO-Link acc. to IEC 61131-9
Connection technology Three-wire
Load current max.250mA(output,permanentlyshort-circuitproof)
Overload resistance yes
Short-circuit resistance Permanently
Switching voltage < 34 V DC
Voltage loss < 3 V
Inverse current PNP < 10 µA
Inverse current NPN < 25 µA
Switching time < 10 ms
Max.cablelengthtotheIO-Linkmaster 20 m (66 ft)
Output Transistor (PNP/NPN)
10.2 Device communication IO-Link
Inthefollowing,thenecessarydevice-specicdetailsareshown.Youcanndfurtherinformationof
IO-Link on www.io-link.com.
Physical layer
IO-Linkspecication:Revision1.1
SIO mode: Yes
Speed: COM2 38.4 kBaud
