24
10 Supplement
VEGAPOINT 11 • Transistor with IO-Link
63008-EN-200527
Min. cycle time 4.0 ms
Length process data word: 32 Bit
IO-Link Data Storage: Yes
Block parameter adjustment: Yes
Direct parameter
Byte Parameter HexCode Note, value
0 - - -
1 MasterCycleTime - -
2 MinCycleTime 0x28 4 ms
3 M-SequenceCapability 0x2B Frametypes, SIO-Mode, ISDU
4 Revision ID 0x11 IO-Link Revision 1.1
5 Input process data length 0xC3 4 Byte
6 Output process data length 0 0 Byte
7, 8 VendorID 0x00,0x62 98
9, 10, 11 DeviceID 0x00,0x02,0x00 1024
Process data word
Conguration
Bit 31 (MSB) … 16 15 … 2 1 0 (LSB)
Sensor X-value 0.1 % (frequency) Temperature in °C, resolution 0.1 K Out2 Out1
Formats
Value Type
Out1 1 Bit Boolean
Out2 1 Bit Boolean
Temperature 14 Bit Integer
X-value 16 Bit Integer
Events
HexCode Type
6202 0x183A FunctionCheck
6203 0x183B Maintenance
6204 0x183C OutOfSpec
6205 0x183D Failure
Device data ISDU
Devicedatacanbeparameters,identicationdataanddiagnosticinformation.Theyareexchanged
acyclically and on request of the IO-Link master. Device data can be written to the sensor (write) or
