10 Supplement
VEGAPOINT 11 • Transistor with IO-Link
63008-EN-200527
readfromthedevice(read).TheISDU(IndexedServiceDataUnit)determines,amongotherthings,
whether the data is read or written.
IO-Linkspecicdevicedata
Designation ISDU (dez) ISDU (hex) Size (Byte) Data type Access Value
DeviceAccess 12 0x000C - - RW -
ProleIdenti-
cation
13 0x000D 2 unsigned8[2] RO 0x40,0x00
PD-Descriptor 14 0x000E 12 unsigned8[12] RO 0x01,0x01,
0x00,0x01,
0x01,0x01,
0x03,0x0E,
0x02,0x03,
0x0E,0x10
VendorName 16 0x0010 31 String RO VEGA Gries-
haber KG
VendorText 17 0x0011 31 String RO www.vega.
com
ProductName 18 0x0012 31 String RO VEGAPOINT
ProductID 19 0x0013 31 String RO VEGAPOINT
11
ProductText 20 0x0014 31 String RO LevelSwitch
SerialNumber 21 0x0015 16 String RO -
HardwareRe-
vision
22 0x0016 20 String RO -
SoftwareRe-
vision
23 0x0017 20 String RO -
Application-
SpecicTag
24 0x0018 Max.31 String RW Sensor
FunctionTag 25 0x0019 Max.31 String RW -
LocationTag 26 0x001A Max.31 String RW -
DeviceStatus 36 0x0024 1 unsigned8[2] RO -
Detailed De-
viceStatus
37 0x0025 12 unsigned8[12] RO -
PDin 40 0x0028 4 - RO see process
word
VEGA-specicdevicedata
Designation ISDU (dez) ISDU (hex) Size
(Byte)
Data type Access Value range
Measurement loop name
(TAG)
256 0x0100 20 String RW -
Application 257 0x0101 1 unsigned8 RW 0=Userdened
1 = Standard
Switching point (SP1) 258 0x0102 4 Float RW -
