10 Supplement
VEGAPOINT 11 • Transistor with IO-Link
63008-EN-200527
Designation ISDU (dez) ISDU (hex) Size
(Byte)
Data type Access Value range
Reset point (RP1) 259 0x0103 4 Float RW -
Switching delay (DS1) 260 0x0104 4 Float RW -
Reset delay (DR1) 261 0x0105 4 Float RW -
Switching point (FH1) 262 0x0106 4 Float RW -
Reset point (FL1) 263 0x0107 4 Float RW -
Switching delay (DS1) 264 0x0108 4 Float RW -
Reset delay (DR1) 265 0x0109 4 Float RW -
Switching point (SP2) 266 0x010A 4 Float RW -
Reset point (RP2) 267 0x010B 4 Float RW -
Switching delay (DS2) 268 0x010C 4 Float RW -
Reset delay (DR2) 269 0x010D 4 Float RW -
Switching point (FH2) 270 0x010E 4 Float RW -
Reset point (FL2) 271 0x010F 4 Float RW -
Switching delay (DS2) 272 0x0110 4 Float RW -
Reset delay (DR2) 273 0x0111 4 Float RW -
Transistor function (P-N) 274 0x0112 1 unsigned8 RW 0 = pnp, 1 = npn
Function output (OU1) 275 0x0113 1 unsigned8 RW 0 = HNO, 1=HNC
2 = FNO, 3=FNC
Function output 2 (OU2) 276 0x0114 1 unsigned8 RW 0 = HNO, 1=HNC
2 = FNO, 3=FNC
Temperature unit (TMP) 291 0x0123 4 Float RW 1001 = °C
1002 = °F
Device status acc. to
NE107
294 0x0126 1 Unsigned8 RO 0 = Good
1 = Function
Check
2 = Maintenance
required
3 = Out of Speci-
cation
4 = Failure
Device status 295 0x0127 19 Unsigned16 RO -
Counter for change of pa-
rameters (PCO)
296 0x0128 4 Unsigned32 RO -
Actual electronics tem-
perature
297 0x0129 4 Float RO -
Min. electronics temper-
ature
299 0x012B 4 Float RO -
Max.electronicstemper-
ature
300 0x012C 4 Float RO -
Actual measuring cell tem-
perature
301 0x011C 4 Float RO -
