10 Supplement
VEGAPOINT 11 • Transistor with IO-Link
63008-EN-200527
Designation ISDU (dez) ISDU (hex) Size
(Byte)
Data type Access Value range
Min. measuring cell tem-
perature
302 0x011D 4 Float RO -
Max.measuringcelltem-
perature
303 0x011E 4 Float RO -
Actual resonance fre-
quency
304 0x0130 4 Float RO -
Min. resonance frequency 305 0x0131 4 Float RO -
Max.resonancefrequency 306 0x0132 4 Float RO -
Probe 307 0x0133 2 Unsigned16 RO 0 = Not Covered
256 = Covered
512 = Covered in-
side Window
768 = Covered
outside Window
Output 308 0x0134 2 Unsigned16 RO 0 = Open
1 = Closed
Output 2 309 0x0135 2 Unsigned16 RO 0 = Open
1 = Closed
Device name 310 0x0136 19 String RO -
Serial number 311 0x0137 16 String RO -
Hardware version 312 0x0138 19 String RO -
Software version 313 0x0139 19 String RO -
Device revision 314 0x013A 2 Unsigned16 RO -
Simulation switching out-
put
315 0x013B 1 Unsigned8 RW 0=O
1= On
Simulation value output 316 0x013C 2 Unsigned16 RW 0 = Open
1= Closed
Simulation switching out-
put 2
317 0x013D 1 Unsigned8 RW 0=O
1= On
Simulation value output 318 0x013E 2 Unsigned16 RW 0 = Open
1= Closed
Device status detailed
status
319 0x013F 4 Unsigned32 RO -
System commands
Designation ISDU (dez) ISDU (hex) Access
Factory Reset 130 0x082 WO
Reset Pointer - Resonance Frequency 161 0x0A1 WO
Reset Pointer - Measuring Cell Temperature 163 0x0A3 WO
Reset Pointer - Electronic Temperature 164 0x0A4 WO
