Vega VEGAPOINT 11 - Dimensions

28
10 Supplement
VEGAPOINT 11 • Transistor with IO-Link
63008-EN-200527
10.3 Dimensions
VEGAPOINT 11, standard version - thread
41 mm
(1.61")
10 mm
(0.39")
ø 18 mm
(0.71")
G
1
/
2
,
G
3
/
4,
G1
98,4 mm
(3.87")
M12 x 1
ø 21,5 mm
(0.85")
15 mm
(0.59")
10 mm
(0.39")
1
/
2
NPT,
3
/
4
NPT
,
1 NPT
98,4 mm
(3.87")
M12 x 1
ø 21,5 mm
(0.85")
SW 21/32
SW 21/32
1 2
Fig. 9: VEGAPOINT 11, standard version - thread
1 Thread G½, G¾, G1 (DIN ISO 228/1) with M12 x 1 plug connection
2 Thread ½ NPT, ¾ NPT, 1 NPT with M12 x 1 plug connection
VEGAPOINT 11, hygienic version - Thread
47,5 mm
(1.87")
10 mm
(0.39")
ø 18 mm
(0.71")
G
1
/
2
98,4 mm
(3.87")
SW22
M12 x 1
12,5 mm
(0.49")
ø 30 mm
(1.18")
ø 50,5 mm
(1.99")
ø 21,5 mm
(0.85")
1 2
Fig. 10: VEGAPOINT 11, hygienic version - Thread
1 Thread G½ for hygienic threaded adapter (DIN ISO 228/1) with M12 x 1 plug connection
2 VEGAPOINT 11, hygienic version in threaded adapter, Clamp
Keepinmindthatthetotallengthisextendedbytheplugconnection.
