80
11 Supplement
VEGAPULS 67 • Probus PA
36533-EN-170405
Fig. 55: VEGAPULS 67: Block diagram with AI FB 1 … AI FB 3 OUT values
TB Transducer Block
FB 1 … FB 3 Function Block
Module of the PA sensors
For the cyclic data trac, VEGAPULS 67 provides the following modules:
•
AI FB1 (OUT)
– Out value of the AI FB1 after scaling
•
AI FB2 (OUT)
– Out value of the AI FB2 after scaling
•
AI FB3 (OUT)
– Out value of the AI FB3 after scaling
•
Free Place
– This module must be used if a value in the data telegram of the cyclical data trac should not
be used (e.g. replacement of temperature and Additional Cyclic Value)
A maximum of three modules can be active. By means of the conguration software of the Probus
master you can determine the conguration of the cyclical data telegram with these modules. The
procedure depends on the respective conguration software.
Note:
The modules are available in two versions:
•
Short for Probus master supporting only one "Identier Format" byte, e.g. Allen
Bradley
