Vega VEGAPULS 67 - Supplement; Technical Data

72
11 Supplement
VEGAPULS 67 • Probus PA
36533-EN-170405
11 Supplement
11.1 Technical data
Note for approved instruments
The technical data in the respective safety instructions are valid for approved instruments (e.g. with
Ex approval). These data can dier from the data listed herein, for example regarding the process
conditions or the voltage supply.
General data
316L corresponds to 1.4404 or 1.4435
Materials, wetted sensor
Ʋ Adapter ange PP-GF30 black
Ʋ Seal, adapter ange FKM (COG VI500), EPDM (COG AP310)
Ʋ Antenna PBT-GF 30
Ʋ Focussing lense PP
Material, wetted parts rinsing connection
Ʋ Rinsing connection PP GFK
Ʋ O-ring seal, rinsing connection FKM (SHS FPM 70C3 GLT), EPDM (COG AP310)
Ʋ Reux valve 316 Ti
Ʋ Sealing, reux valve FKM (SHS FPM 70C3 GLT), EPDM (COG AP310)
Materials, non-wetted parts
Ʋ Compression ange PP-GF30 black
Ʋ Mounting strap 316L
Ʋ Fixing screws, mounting strap 316L
Ʋ Fixing screws, adapter ange 304
Ʋ Plastic housing plastic PBT (Polyester)
Ʋ Aluminium die-cast housing Aluminium die-casting AlSi10Mg, powder-coated (basis:
Polyester)
Ʋ Stainless steel housing 316L
Ʋ Cable gland PA, stainless steel, brass
Ʋ Sealing: cable gland NBR
Ʋ Blind plug: cable gland PA
Ʋ Seal between housing and housing lid Silicone SI 850 R, NBR silicone-free
Ʋ Inspection window in housing cover
(optional)
Polycarbonate
Ʋ Ground terminal 316L
Process ttings
Ʋ Flanges DIN from DN 80, ASME from 3", JIS from DN 100 10K
Weight depending on process tting and
housing material
0.7 … 3.4 kg (1.543 … 7.496 lbs)
