11
VEGAPULS 6X
1022892-EN-240312
•
Air with an oxygen content of 21 % (v/v)
Additional measures are required for operation of the VEGAPULS 6X outside these conditions.
The operation of the VEGAPULS 6X outside the above conditions is the sole responsibility of the
operator.
The thermal measurements for determining the following temperature tables were carried out for
process temperatures above +150 °C with insulation. Thermal measurements up to +150 °C were
carried out without insulation.
Data sheets of the insulation used:
SiBa20/150a/ALU50 SiBa/-a
Data sheet extract insulation Aluminium foil embossed
Basalt/silica compound eece
Basalt/silica compound eece
General technical data SiBa 20/150a/ALU50 is a mechani-
cally bonded needlefelt based on a
mixture of endless drawn basalt -
bres and silica bres, laminated with
an aluminium foil (thickness approx.
50 µm).
It is a mechanically bonded needle-
felt based on a mixture of continuously
drawn basalt bres (approx. 70 %) and
silica bres (approx. 30 %).
Thickness [mm] approx. 20 approx. 20
Grammage [kg/m
2
] approx. 3 approx. 3
Bulk density [kg/m
2
] approx. 150 approx. 150
Heat resistance in the
long term
[°C] up to 700
Radiant heat on aluminium max. 250
up to 700
Heat resistance in the
short term
[°C] up to 700 up to 700
Cold resistance [°C] up to -40 up to -40
Heat conductivity [W/mK] 0.05 (at 200 °C)
0.15 (at 600 °C)
0.05 (at 200 °C)
0.15 (at 600 °C)
Vibration behaviour Resistant Resistant
Physiological behav-
iour
Harmless Harmless
Toxicological behav-
iour
Not dangerous Not dangerous
Filament diameter [µm] > 6 > 6
Flammability Fire-proof Fire-proof
For measurements with insulation, a layer thickness of 8 cm SiBa 20/150a was applied. Look-
ing from the surface of the tank, a 6 cm layer of SiBa 20/150a was rst applied. A 2 cm layer of
SiBa 20/150a/ALU50 was then nally applied on top of this layer.
Max.temperatureofVEGAPULS6Xwhenusedinexplosiveatmosheres:
Max. permissible ambient temperature: -40 … +60 °C
Maximum surface temperature of any surface for class III
that can come in contact with the atmosphere
+165 °C
