Vega VEGAPULS 6X Series - Application Area Overview; Application Areas for Electronics Version W

6
VEGAPULS 6X
1022892-EN-240312
p FunctionalsafetySIL(IEC61508)
* with
q ITSecurity(IEC62443-4-2)
X without
* with
r Overllprotection
X without
* with
s Food/pharmaceuticalcerticate
X without
* with
t Shipapproval
X without
* with
u SecondaryLineofDefense
X without
S with
3 Applicationarea
Division-TheVEGAPULS6XaresuitableforapplicationsDivision2
ApplicationareaofVEGAPULS6X(electronicsversionW):
Type code Explosion
group
Typeofprotectionmarking
Electronics version "W" - four-wire Modbus
PS6X(*).2*W*********W*A****** Groups A, B, C,
D, F, G
Cl l, Div 2, Gp ABCD T6…T1;
Cl II, Div 2 Gp FG, T*°C; Cl III;
Dual Seal
Ta = -40 … +60 °C
Environmentaldesignation:
Housing Electronics Version Dual
Seal
Typeofprotection
Aluminium, stainless steel (precision cast-
ing) double chamber
W D, S, W yes IP66/68 (0.2bar), TYPE 4X/6P
ANSI/UL 50E, CSA C22.2 No. 94.2, NEMA ratings
