Vega VEGAPULS 6X Series - Thermal Data for Gas Applications

12
VEGAPULS 6X
1022892-EN-240312
9.2 Thermaldata-Gas
VEGAPULS6Xwithplastichornantennaforprocesstemperaturesuptomax.+80°C
PS6X(*).2*W**B*AT/AU/AV************
Aluminium/stainlesssteelhousing,versionA,H,D,S,V,W
T-class Permissibleprocesstem-
peraturerangeonthe
antennainzone0(EPLGa)
Permissibleambienttemperaturerangeontheelectronics
inzone1(EPLGb)
withoutinspectionwindow withinspectionwindow
T6 … T1 -40 … +80 °C -60 … +75 °C -50 … +75 °C
VEGAPULS6Xwithlensantennaforprocesstemperaturesuptomax.+150°C
PS6X(*).2*W**C**************
Aluminiumhousing,versionA,H,D,S
T-class Permissibleprocesstem-
peraturerangeonthe
antennainzone0(EPLGa)
Permissibleambienttemperaturerangeontheelectronics
inzone1(EPLGb)
withoutinspectionwindow withinspectionwindow
T6 -60 … +80 °C -60 … +75 °C -50 … +75 °C
T5 -60 … +95 °C -60 … +72 °C -50 … +72 °C
T4 -60 … +130 °C -60 … +65 °C -50 … +65 °C
T3 … T1 -60 … +150 °C -60 … +61 °C -50 … +61 °C
Stainlesssteelhousing,versionV,W
T-class Permissibleprocesstem-
peraturerangeonthe
antennainzone0(EPLGa)
Permissibleambienttemperaturerangeontheelectronics
inzone1(EPLGb)
withoutinspectionwindow withinspectionwindow
T6 -60 … +80 °C -60 … +75 °C -50 … +75 °C
T5 -60 … +95 °C -60 … +70 °C -50 … +70 °C
T4 -60 … +130 °C -60 … +59 °C -50 … +59 °C
T3 … T1 -60 … +150 °C -60 … +52 °C -50 … +52 °C
VEGAPULS6Xwithlensantennaforprocesstemperaturesuptomax.+195°C
PS6X(*).2*W**C**************
Aluminiumhousing,versionA,H,D,S
T-class Permissibleprocesstem-
peraturerangeonthe
antennainzone0(EPLGa)
Permissibleambienttemperaturerangeontheelectronics
inzone1(EPLGb)
withoutinspectionwindow withinspectionwindow
T6 -60 … +80 °C -60 … +75 °C -50 … +75 °C
