7 Electrostaticcharging(ESD)
In case of instrument versions with electrostatically chargeable plastic parts, the danger of electro-
static charging and discharging must be taken into account!
The following parts can charge and discharge:
•
Lacquered housing version or alternative special lacquering
•
Plastic housing, plastic housing parts
•
Plastic process ttings
•
Plastic-coated process ttings and/or plastic-coated sensors
•
Connection cable for separate versions
•
Type label
Take note in case of danger of electrostatic charges:
•
Avoid friction on the surfaces
•
Do not dry clean the surfaces
The instruments must be installed in such a way that the following can be ruled out:
•
electrostatic charges during operation, maintenance and cleaning.
•
process-related electrostatic charges, e.g. by measuring media owing past
The warning label indicates danger:
WARNING -- POTENTIAL ELECTROSTATIC CHARGING
HAZARD -- SEE INSTRUCTIONS
AVERTISSEMENT -- DANGER POTENTIEL DE CHARGES
ÉLECTROSTATIQUES -- VOIR INSTRUCTIONS
8 Electricaldata
For the VEGAPULS 6X in type of protection Nonincendive applies:
PS6X(*).2*W*********W*A******
Supply circuit: terminals 1[+], 2[-]
Supply circuit: terminals 3[D0], 4[D1]
Terminals 5[IS GND]
USB connection
Terminals 1, 2, 3, 4, 5, USB in connection compartment
U = 8 … 30 V DC
U
max
= 5 V with Modbus signal (tel-
egram)
Function when installing according
to CSA (Canadian Standards As-
sociation)
U
max
= 5 V with USB signal (USB
protocol)
Displayandadjustmentcircuit
Indication and adjustment circuit: (spring contacts) For connection to the display and
adjustment module PLICSCOM.
9 Thermaldata
9.1 Thermaldata-Generalregulations
The approval is valid under the following conditions:
•
Compliance with the temperature ranges for the various versions as indicated in the tables
below.
•
Pressure: 80 kPa (0.8 bar) to 110 kPa (1.1 bar), and
