Vega VEGAPULS 6X Series User Manual

3
VEGAPULS 6X
1022892-EN-240312
1 Scope
These safety instructions apply to the radar sensors VEGAPULS 6X of type series:
•
PS6X(*).a-b-c-de-f-g-hi-j-k-l-m-*A-p-q-r-s-t-u
With the electronics versions:
•
W - Four-wire Modbus
The VEGAPULS 6X are approved acc. to c-CSA-us:
CSA 22 CA 80127301 (certicate number on the type label)
The classication as well as the respective standards are stated in the Certicate of Conformity.
Type of protection marking:
•
Cl l, Div 2, Gp ABCD T6…T1;
•
Cl II, Div 2 Gp FG, T*°C; Cl III;
•
Dual Seal
•
Ta = -40 … +60 °C
2 Typecodespecication
In the following, all versions are called VEGAPULS 6X. If parts of these safety instructions refer only
to certain versions, then these will be mentioned explicitly with their type code.
VEGAPULS6XwithtypecodePS6X(*).a-b-c-de-f-g-hi-j-k-l-m-no-p-q-r-s-t-u
a Generation
2 Second generation
b Application
* One-digit code for preselection, not relevant for approval
c Radartechnology
W 80 GHz
de Processtting/Material
XX universal, plastic horn antenna / PP/PBT
XC Mounting strap, length: 170 mm / 316L/316L
XD Mounting strap, length: 300 mm / 316L/316L
** Other process ttings that comply with national or international standards
f Antennaversion
B Plastic horn antenna
T Thread with integrated antenna system
F Flange with plastic plating
C Flange with lens antenna
H Hygienic tting
G with horn antenna (ø 19 mm)
K with horn antenna (ø 25 mm)
