14 Supplement
VEGAPULS C 21 • Modbus and Levelmaster protocol
58343-EN-200806
Mechanical environmental conditions
Vibrations
Class 4M8 acc. to IEC 60271-3-4 (5 g at 4 ... 200 Hz)
Impacts (mechanical shock) Class 6M4 acc. to IEC 60271-3-6 (50 g, 2.3 ms)
Impact resistance IK07 acc. to IEC 62262
Process conditions
Fortheprocessconditions,pleasealsonotethespecicationsonthetypelabel.Thelowestvalue
(amount) always applies.
Process temperature
-40 … +80 °C (-40 … +176 °F)
Process pressure -1 … 3 bar (-100 … 300 kPa/-14.5 … 43.51 psig)
Electromechanical data
Cable entry Fixed connection
Connection cable
Ʋ Conguration Wires, screen braiding, sheathing
Ʋ Wire cross-section 0.5 mm² (AWG 20)
Ʋ Min. bending radius (at 25 °C/77 °F) 25 mm (0.984 in)
Ʋ Diameter approx. 6 mm (0.236 in)
Ʋ Wire isolating and cable cover PUR
Ʋ Colour Black
Ʋ Flame retardant according to IEC 60332-1-2, UL 1581 (Flametest VW-1)
Bluetooth interface
Bluetooth standard Bluetooth 5.0 (downward compatible to Bluetooth
4.0 LE)
Frequency 2.402 … 2.480 GHz
Max. emitted power +2.2 dBm
Max. number of participants 1
Eectiverangetyp.
13)
25 m (82 ft)
Adjustment
PC/Notebook PACTware/DTM
Smartphone/Tablet Adjustment app
Voltage supply
Operating voltage
8 … 30 V DC
Power consumption without/with bus communication typ. at
Ʋ 12 DC 150 mW/330 mW
Ʋ 24 V DC 240 mW/420 mW
Reverse voltage protection Integrated
13)
Depending on the local conditions
