Features
TheVXMisahighperformance,advanceddesignsteppingmotorcontroller.
Highreliability,andconsistentperformanceareachievedbythesedesign
features:
Singlechipmicrocontroller(MCU)digitallycontrolsthemotorphaseswitching
andallotherinterfacefunctions(noisesensitivestepanddirectiontranslation
circuitryareeliminated)
Pulsewidthmodulatedtimingispresetby
theMCU,eliminatingerrorprone
analogfeedbackcircuits
Regulatedpowersupplywitha100to240VACinputrangeassuresconsistent
motoroutputtorque
4Xoversizemotordrivesforlonglifeandoverloadtolerance
AsingleVXMcanacceptandexecutecommandsforoperating4motors
CompleteController/Indexer/Driver/ACPowerSupplywithRS-232interface
Modulated
currentcontroldrivehaslesslowspeedvibrationthantypical400
step/revcontrollers
Nonvolatilememoryforuserprogramstorage
IncludedexternaldesktoptypepowersupplyisUL,CE,CSA,andTUVsafety
agencycompliant
Oneandtwomotorversions. Threeandfourmotorcapabilitywithtwo
ControlslinkedbytheVXMbus
Backwardcompatible
withVelmexNF90andVP9000StepMotorcontrollers
Userprogrammableinputsandoutputs
10bitanaloginputforexternalsensor,settingspeed,orforanalogjoystick
control
Runs6or8leadpermanentmagnetstepmotorsratedfrom0.4to4.7amps
Jog,Run,andStopinputbuttonsonfrontpanel
Useinteractivelywith
aPCorrunstandalone
Opticallyisolatedlimitswitchinputs
Userresettablecircuitbreakerprotected
Softwaresettablemotorpowerandmotormodelselection
Lowvoltage24VDCoperation
Energysavingdesign,automaticallyde-energizesmotorsatastandstill,
consumingonly1.4watts
FIFObuffertocapturemotorpositionsonexternaltrigger
Specialcommandsformatrix/arraypatterns
andpick-and-placeapplications
Conditionalcommandstoskipornottoskipnextcommandoninputstate
CoordinatedmotionwithtwoVXMs
Complexmotionprofileswith“continuousindexmode”
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
·
