Outline Dimensions

Appendix Q

7

2.24"(57.0mm)

T-SLOTFOR#4ORM4NUT

4PLACES

1.80"(45.7mm)

6.59"(167.4mm)

3.29"(83.6mm)

0.25"(6.4mm)

4.36"(110.7mm)

VXM
